GS-310S automatic Mini type boards Splicing box making machine
1. Function :
1.GS -310S automatic splicing boards box making machine is specially develop to solve the problem of raw paper materials waste, tape mark after wrapping paper....
2.It is widely used in the production of mobile phone box, shoes box, tea box, wine box, moon cake box, gift boxes and other luxury box.
2. Features:
1.This machine adopts the technology of three boards box making. it use microcomputer to control the bottom plate and sides plate to make up the box, which greatly saves the cost of raw materials.
2.The machine adopts automatic Omron PLC touching screen which display data, operate and control system cleanly, and also display fault detection and alarm. It is easy operate.
3.This machine uses the hot melt glue to make up box replace of use tape , which adjust the spray adhesive length, width, starting point and ending point according to the product requirements. It is easy operate.
4.The machine adopts the unique downdraught feeding, which can feed baseboard and side plate with non-stop machine and achieve continuous production.
3.Advantages:优势
1).High speed, 35-45pcs/min.
2)Small space for machine body.
3).Easy operate, high precision boxes.
4).Protect cover with machines.(option)
4. Main Technical Parameters:
Mode |
GS-310S |
Paper thickness |
1.5—5MM |
Max box size: |
220*150*100(LxWxH)(outside) |
Min box size |
100*60*20mm(LxWxH)(innner) |
produce speed |
35~45pcs/min |
Glue loader capacity |
6L |
Air supply requirements |
300L/min 0.8Mpa |
Glue type |
Hot-melt glue |
Power |
5.5KW/380v |
Machine size |
800Kg |
Machine size: |
1700MM*1300MM*1900MM |
